Please enter your laser wavelength and use the filter products below.
Moreover, for a quick quotation for products you see in the table, please check all the desired PNs at the last column of the table and click on the RFQ calculator icon at the column title.
Need shorter lead time? Lead time of uncoated DOE is 5 weeks shorter! Click here for questions.
PN | λ [nm] | Number of Spots | Separation Angle [deg] | θf [deg] | Availability | Remarks | Add to Quote | |
---|---|---|---|---|---|---|---|---|
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-001-A-Y-A | 1064 | 2 | 0.14 | 0.14 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.27
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-002-I-Y-A | 1064 | 2 | 0.27 | 0.27 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.27
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.54
θf [deg]:2.54
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-006-I-Y-A | 1064 | 2 | 2.54 | 2.54 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.54
θf [deg]:2.54
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.15
θf [deg]:0.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-025-A-Y-A | 1064 | 2 | 0.15 | 0.15 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.15
θf [deg]:0.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.69
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.099
θf [deg]:0.099
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-026-A-Y-A | 1064 | 2 | 0.099 | 0.099 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.69
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.099
θf [deg]:0.099
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.69
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.5
Thickness [mm]:1.5
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.099
θf [deg]:0.099
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-029-A-Y-A | 1064 | 2 | 0.099 | 0.099 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.69
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.5
Thickness [mm]:1.5
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.099
θf [deg]:0.099
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:20.01
θf [deg]:20.01
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<5 |
||||||||
DS-032-Q-Y-A | 1064 | 2 | 20.01 | 20.01 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:20.01
θf [deg]:20.01
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:10.17
θf [deg]:10.17
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
DS-033-I-Y-A | 1064 | 2 | 10.17 | 10.17 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:10.17
θf [deg]:10.17
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>9.50
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.038
θf [deg]:0.038
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-034-I-Y-A | 1064 | 2 | 0.038 | 0.038 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>9.50
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.038
θf [deg]:0.038
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>11.61
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.032
θf [deg]:0.032
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-180-I-Y-A | 1064 | 2 | 0.032 | 0.032 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>11.61
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.032
θf [deg]:0.032
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>11.61
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.032
θf [deg]:0.032
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-181-I-Y-A | 1064 | 2 | 0.032 | 0.032 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>11.61
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.032
θf [deg]:0.032
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.79
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.076
θf [deg]:0.076
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-182-I-Y-A | 1064 | 2 | 0.076 | 0.076 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.79
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.076
θf [deg]:0.076
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.79
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.076
θf [deg]:0.076
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-183-I-Y-A | 1064 | 2 | 0.076 | 0.076 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.79
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.076
θf [deg]:0.076
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.91
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.094
θf [deg]:0.094
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-184-I-Y-A | 1064 | 2 | 0.094 | 0.094 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.91
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.094
θf [deg]:0.094
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-185-I-Y-A | 1064 | 2 | 0.14 | 0.14 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.7
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-186-I-Y-A | 1064 | 2 | 0.14 | 0.14 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.7
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.18
θf [deg]:0.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-187-I-Y-A | 1064 | 2 | 0.18 | 0.18 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.18
θf [deg]:0.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.18
θf [deg]:0.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-188-I-Y-A | 1064 | 2 | 0.18 | 0.18 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.18
θf [deg]:0.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.73
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.50
θf [deg]:0.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-189-I-Y-A | 1064 | 2 | 0.50 | 0.50 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.73
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.50
θf [deg]:0.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.92
θf [deg]:0.92
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-190-I-Y-A | 1064 | 2 | 0.92 | 0.92 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.92
θf [deg]:0.92
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.92
θf [deg]:0.92
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-191-I-Y-A | 1064 | 2 | 0.92 | 0.92 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.92
θf [deg]:0.92
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.38
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.96
θf [deg]:0.96
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-192-I-Y-A | 1064 | 2 | 0.96 | 0.96 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.38
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.96
θf [deg]:0.96
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.38
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.96
θf [deg]:0.96
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-193-I-Y-A | 1064 | 2 | 0.96 | 0.96 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.38
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.96
θf [deg]:0.96
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.05
θf [deg]:1.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-194-I-Y-A | 1064 | 2 | 1.05 | 1.05 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.05
θf [deg]:1.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.05
θf [deg]:1.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-195-I-Y-A | 1064 | 2 | 1.05 | 1.05 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.05
θf [deg]:1.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.09
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:4.13
θf [deg]:4.13
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
DS-196-I-Y-A | 1064 | 2 | 4.13 | 4.13 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.09
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:4.13
θf [deg]:4.13
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:5.08
θf [deg]:5.08
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
DS-197-I-Y-A | 1064 | 2 | 5.08 | 5.08 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:5.08
θf [deg]:5.08
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:7.63
θf [deg]:7.63
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
DS-198-I-Y-A | 1064 | 2 | 7.63 | 7.63 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:7.63
θf [deg]:7.63
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:8.72
θf [deg]:8.72
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
DS-199-I-Y-A | 1064 | 2 | 8.72 | 8.72 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:8.72
θf [deg]:8.72
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
Input Parameters
Wavelength [nm]:10600
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Lens
Material:ZnSe
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:2.5
Radius of Curvature [mm]:137.5
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:2 mm
θf [deg]:2 mm
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-202-A-Y-A | 10600 | 2 | 2 mm | 2 mm | In Stock | Lens PLCX BFL= 98mm, Notch | ||
Input Parameters
Wavelength [nm]:10600
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Lens
Material:ZnSe
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:2.5
Radius of Curvature [mm]:137.5
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:2 mm
θf [deg]:2 mm
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:10600
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.00
Element Parameters
Element Type:Lens
Material:ZnSe
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:2.5
Radius of Curvature [mm]:112.6
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.3 mm
θf [deg]:1.3 mm
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-203-A-Y-A | 10600 | 2 | 1.3 mm | 1.3 mm | In Stock | Lens PLCX BFL= 80mm, Notch | ||
Input Parameters
Wavelength [nm]:10600
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.00
Element Parameters
Element Type:Lens
Material:ZnSe
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:2.5
Radius of Curvature [mm]:112.6
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.3 mm
θf [deg]:1.3 mm
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:10600
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Lens
Material:ZnSe
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:2.5
Radius of Curvature [mm]:112.6
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:2 mm
θf [deg]:2 mm
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-204-A-Y-A | 10600 | 2 | 2 mm | 2 mm | In Stock | Lens PLCX BFL= 80mm, Notch | ||
Input Parameters
Wavelength [nm]:10600
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Lens
Material:ZnSe
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:2.5
Radius of Curvature [mm]:112.6
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:2 mm
θf [deg]:2 mm
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:10600
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.00
Element Parameters
Element Type:Lens
Material:ZnSe
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:2.5
Radius of Curvature [mm]:139
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.3 mm
θf [deg]:1.3 mm
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-205-A-Y-A | 10600 | 2 | 1.3 mm | 1.3 mm | In Stock | Lens PLCX BFL= 98mm, Notch | ||
Input Parameters
Wavelength [nm]:10600
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.00
Element Parameters
Element Type:Lens
Material:ZnSe
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:2.5
Radius of Curvature [mm]:139
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.3 mm
θf [deg]:1.3 mm
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:10600
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.40
Element Parameters
Element Type:Window
Material:ZnSe
Element Size [mm]:15
Clear Aperture [mm]:13.5
Thickness [mm]:1.5
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.15
θf [deg]:0.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-207-A-Y-A | 10600 | 2 | 0.15 | 0.15 | 8 weeks | |||
Input Parameters
Wavelength [nm]:10600
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.40
Element Parameters
Element Type:Window
Material:ZnSe
Element Size [mm]:15
Clear Aperture [mm]:13.5
Thickness [mm]:1.5
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.15
θf [deg]:0.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.27
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-208-I-Y-A | 1064 | 2 | 0.27 | 0.27 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.27
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.49
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.15
θf [deg]:0.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-209-I-Y-A | 1064 | 2 | 0.15 | 0.15 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.49
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.15
θf [deg]:0.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.29
θf [deg]:0.29
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-210-I-Y-A | 1064 | 2 | 0.29 | 0.29 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.29
θf [deg]:0.29
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.43
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.25
θf [deg]:0.25
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-212-I-Y-A | 1064 | 2 | 0.25 | 0.25 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.43
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.25
θf [deg]:0.25
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>9.69
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.038
θf [deg]:0.038
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-213-A-Y-A | 1064 | 2 | 0.038 | 0.038 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>9.69
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.038
θf [deg]:0.038
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.39
θf [deg]:3.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-215-I-Y-A | 1064 | 2 | 3.39 | 3.39 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.39
θf [deg]:3.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.24
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.52
θf [deg]:1.52
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-216-I-Y-A | 1064 | 2 | 1.52 | 1.52 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.24
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.52
θf [deg]:1.52
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.27
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-217-I-Y-A | 1064 | 2 | 0.27 | 0.27 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.27
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12x12
Clear Aperture [mm]:10.8x10.8
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:64.28
θf [deg]:64.28
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
DS-219-I-Y-A | 1064 | 2 | 64.28 | 64.28 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12x12
Clear Aperture [mm]:10.8x10.8
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:64.28
θf [deg]:64.28
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12x12
Clear Aperture [mm]:10.8x10.8
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:30.85
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
DS-220-I-Y-A | 1064 | 2 | 30.85 | 30.85 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12x12
Clear Aperture [mm]:10.8x10.8
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:30.85
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.17
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.18
θf [deg]:2.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-222-I-Y-A | 1064 | 2 | 2.18 | 2.18 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.17
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.18
θf [deg]:2.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.35
θf [deg]:1.35
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-223-A-Y-A | 1064 | 2 | 1.35 | 1.35 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.35
θf [deg]:1.35
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.12
θf [deg]:0.12
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-224-I-Y-A | 1064 | 2 | 0.12 | 0.12 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.12
θf [deg]:0.12
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.10
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.67
θf [deg]:3.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-225-I-Y-A | 1064 | 2 | 3.67 | 3.67 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.10
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.67
θf [deg]:3.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.39
θf [deg]:3.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-226-I-Y-A | 1064 | 2 | 3.39 | 3.39 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.39
θf [deg]:3.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.13
θf [deg]:3.13
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-227-I-Y-A | 1064 | 2 | 3.13 | 3.13 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.13
θf [deg]:3.13
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.13
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.90
θf [deg]:2.90
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-228-I-Y-A | 1064 | 2 | 2.90 | 2.90 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.13
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.90
θf [deg]:2.90
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.71
θf [deg]:2.71
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-229-I-Y-A | 1064 | 2 | 2.71 | 2.71 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.71
θf [deg]:2.71
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.44
θf [deg]:2.44
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-230-I-Y-A | 1064 | 2 | 2.44 | 2.44 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.44
θf [deg]:2.44
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:30.85
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
DS-231-I-Y-A | 1064 | 2 | 30.85 | 30.85 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:30.85
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:8
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:5.42
θf [deg]:5.42
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
DS-234-I-Y-A | 1064 | 2 | 5.42 | 5.42 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:8
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:5.42
θf [deg]:5.42
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.20
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.79
θf [deg]:1.79
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-235-I-Y-A | 1064 | 2 | 1.79 | 1.79 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.20
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.79
θf [deg]:1.79
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10.7x10.7
Clear Aperture [mm]:9.6x9.6
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:30.85
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
DS-236-I-Y-A | 1064 | 2 | 30.85 | 30.85 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10.7x10.7
Clear Aperture [mm]:9.6x9.6
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:30.85
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:18.41
θf [deg]:18.41
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<4 |
||||||||
DS-237-I-Y-A | 1064 | 2 | 18.41 | 18.41 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:18.41
θf [deg]:18.41
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<4 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.26
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.42
θf [deg]:1.42
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-238-I-Y-A | 1064 | 2 | 1.42 | 1.42 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.26
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.42
θf [deg]:1.42
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.18
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.00
θf [deg]:2.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-239-I-Y-A | 1064 | 2 | 2.00 | 2.00 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.18
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.00
θf [deg]:2.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:41.55
θf [deg]:41.55
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<4 |
||||||||
DS-240-I-Y-A | 1064 | 2 | 41.55 | 41.55 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:41.55
θf [deg]:41.55
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<4 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.90
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.41
θf [deg]:0.41
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-241-I-Y-A | 1064 | 2 | 0.41 | 0.41 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.90
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.41
θf [deg]:0.41
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.45
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.11
θf [deg]:0.11
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-242-I-Y-A | 1064 | 2 | 0.11 | 0.11 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.45
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.11
θf [deg]:0.11
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.084
θf [deg]:0.084
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-243-I-Y-A | 1064 | 2 | 0.084 | 0.084 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.084
θf [deg]:0.084
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.35
θf [deg]:0.35
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-244-I-Y-A | 1064 | 2 | 0.35 | 0.35 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.35
θf [deg]:0.35
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.10
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x14
Clear Aperture [mm]:12x12
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.59
θf [deg]:3.59
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-248-I-Y-A | 1064 | 2 | 3.59 | 3.59 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.10
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x14
Clear Aperture [mm]:12x12
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.59
θf [deg]:3.59
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x14
Clear Aperture [mm]:12x12
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.21
θf [deg]:3.21
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-249-I-Y-A | 1064 | 2 | 3.21 | 3.21 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x14
Clear Aperture [mm]:12x12
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.21
θf [deg]:3.21
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x14
Clear Aperture [mm]:12x12
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.05
θf [deg]:3.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-250-I-Y-A | 1064 | 2 | 3.05 | 3.05 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x14
Clear Aperture [mm]:12x12
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:3.05
θf [deg]:3.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x14
Clear Aperture [mm]:12x12
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.71
θf [deg]:2.71
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-251-I-Y-A | 1064 | 2 | 2.71 | 2.71 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x14
Clear Aperture [mm]:12x12
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.71
θf [deg]:2.71
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x14
Clear Aperture [mm]:12x12
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.54
θf [deg]:2.54
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-252-I-Y-A | 1064 | 2 | 2.54 | 2.54 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x14
Clear Aperture [mm]:12x12
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.54
θf [deg]:2.54
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:20.43
θf [deg]:20.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<4 |
||||||||
DS-253-I-Y-A | 1064 | 2 | 20.43 | 20.43 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:20.43
θf [deg]:20.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<4 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.72
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.064
θf [deg]:0.064
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-255-I-Y-A | 1064 | 2 | 0.064 | 0.064 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.72
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.064
θf [deg]:0.064
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.81
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.45
θf [deg]:0.45
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-256-I-Y-A | 1064 | 2 | 0.45 | 0.45 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.81
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.45
θf [deg]:0.45
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.60
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.23
θf [deg]:0.23
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-257-I-Y-A | 1064 | 2 | 0.23 | 0.23 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.60
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.23
θf [deg]:0.23
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>7.98
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.046
θf [deg]:0.046
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-258-I-Y-A | 1064 | 2 | 0.046 | 0.046 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>7.98
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.046
θf [deg]:0.046
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>7.92
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.046
θf [deg]:0.046
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-259-I-Y-A | 1064 | 2 | 0.046 | 0.046 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>7.92
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.046
θf [deg]:0.046
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>7.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.052
θf [deg]:0.052
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-260-I-Y-A | 1064 | 2 | 0.052 | 0.052 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>7.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.052
θf [deg]:0.052
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.4
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-261-A-Y-A | 1064 | 2 | 0.14 | 0.14 | In Stock | Suppressed undesired orders | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.4
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.00
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:90.36
θf [deg]:90.36
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
DS-262-I-Y-A | 1064 | 2 | 90.36 | 90.36 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.00
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:90.36
θf [deg]:90.36
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:50.38
θf [deg]:50.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-263-I-Y-A | 1064 | 2 | 50.38 | 50.38 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:50.38
θf [deg]:50.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:35.40
θf [deg]:35.40
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
DS-264-I-Y-A | 1064 | 2 | 35.40 | 35.40 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:35.40
θf [deg]:35.40
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.36
θf [deg]:0.36
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-265-I-Y-A | 1064 | 2 | 0.36 | 0.36 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.36
θf [deg]:0.36
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.15
θf [deg]:1.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-267-I-Y-A | 1064 | 2 | 1.15 | 1.15 | 6 weeks | High Efficiency (CV HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.15
θf [deg]:1.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-268-I-Y-A | 1064 | 2 | 0.14 | 0.14 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 97
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-269-I-Y-A | 1064 | 2 | 0.14 | 0.14 | In Stock | High Efficiency (CV HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 97
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.54
θf [deg]:0.54
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-270-I-Y-A | 1064 | 2 | 0.54 | 0.54 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.54
θf [deg]:0.54
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.68
θf [deg]:0.68
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-271-I-Y-A | 1064 | 2 | 0.68 | 0.68 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.68
θf [deg]:0.68
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.16
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.32
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-273-I-Y-A | 1064 | 2 | 0.32 | 0.32 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.16
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.32
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.03
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:14.38
θf [deg]:14.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<4 |
||||||||
DS-274-I-Y-A | 1064 | 2 | 14.38 | 14.38 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.03
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:14.38
θf [deg]:14.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<4 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.81
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.45
θf [deg]:0.45
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-276-I-Y-A | 1064 | 2 | 0.45 | 0.45 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.81
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.45
θf [deg]:0.45
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.09
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:4.10
θf [deg]:4.10
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-277-I-Y-A | 1064 | 2 | 4.10 | 4.10 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.09
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:4.10
θf [deg]:4.10
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.06
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:5.91
θf [deg]:5.91
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
DS-278-I-Y-A | 1064 | 2 | 5.91 | 5.91 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.06
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:5.91
θf [deg]:5.91
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.03
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.5
Clear Aperture [mm]:8
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:14.38
θf [deg]:14.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<4 |
||||||||
DS-281-I-Y-A | 1064 | 2 | 14.38 | 14.38 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.03
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.5
Clear Aperture [mm]:8
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:14.38
θf [deg]:14.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<4 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.7x12.7
Clear Aperture [mm]:11.4x11.4
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.54
θf [deg]:2.54
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-283-I-Y-A | 1064 | 2 | 2.54 | 2.54 | 8 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.7x12.7
Clear Aperture [mm]:11.4x11.4
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.54
θf [deg]:2.54
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:30.85
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
DS-284-I-Y-A | 1064 | 2 | 30.85 | 30.85 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:30.85
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<3 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.22
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.63
θf [deg]:1.63
Transmission efficiency:Close to 100%
Overall Efficiency:~ 94
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-285-I-Y-A | 1064 | 2 | 1.63 | 1.63 | 6 weeks | High Efficiency (CV HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.22
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.63
θf [deg]:1.63
Transmission efficiency:Close to 100%
Overall Efficiency:~ 94
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:6.86
θf [deg]:6.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-286-I-Y-A | 1064 | 2 | 6.86 | 6.86 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:6.86
θf [deg]:6.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.03
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:11.23
θf [deg]:11.23
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-287-I-Y-A | 1064 | 2 | 11.23 | 11.23 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.03
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:11.23
θf [deg]:11.23
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.31
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:7
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.19
θf [deg]:1.19
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-288-I-Y-A | 1064 | 2 | 1.19 | 1.19 | 6 weeks | High Efficiency (CV HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.31
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:7
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:1.19
θf [deg]:1.19
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13x13
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:17.49
θf [deg]:17.49
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<4 |
||||||||
DS-289-I-Y-A | 1064 | 2 | 17.49 | 17.49 | 8 weeks | Pattern rotated 45deg | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13x13
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:17.49
θf [deg]:17.49
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<4 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.16
θf [deg]:0.16
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-291-I-Y-A | 1064 | 2 | 0.16 | 0.16 | 6 weeks | High Efficiency (Scan HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.16
θf [deg]:0.16
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.09
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.34
θf [deg]:0.34
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-292-I-Y-A | 1064 | 2 | 0.34 | 0.34 | 6 weeks | High Efficiency (Scan HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.09
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.34
θf [deg]:0.34
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.16
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.32
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]: |
||||||||
DS-293-I-Y-A | 1064 | 2 | 0.32 | 0.32 | 6 weeks | High Efficiency (Half Scan HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.16
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.32
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]: |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.67
θf [deg]:0.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 94
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]: |
||||||||
DS-294-I-Y-A | 1064 | 2 | 0.67 | 0.67 | 6 weeks | High Efficiency (Half Scan HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.67
θf [deg]:0.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 94
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]: |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:0.95
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:7.31
θf [deg]:7.31
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-304-I-Y-A | 1064 | 2 | 7.31 | 7.31 | 8 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:0.95
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:7.31
θf [deg]:7.31
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 97
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-306-I-Y-A | 1064 | 2 | 0.14 | 0.14 | 6 weeks | High Efficiency (CV HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 97
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:22x22
Clear Aperture [mm]:19.8x19.8
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:7.31
θf [deg]:7.31
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-311-I-Y-A | 1064 | 2 | 7.31 | 7.31 | 8 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:22x22
Clear Aperture [mm]:19.8x19.8
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:7.31
θf [deg]:7.31
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.57
θf [deg]:0.57
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-314-I-Y-A | 1064 | 2 | 0.57 | 0.57 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.57
θf [deg]:0.57
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.9
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:10.30
θf [deg]:10.30
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-319-I-Y-A | 1064 | 2 | 10.30 | 10.30 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.9
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:10.30
θf [deg]:10.30
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.9
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:8.66
θf [deg]:8.66
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-320-I-Y-A | 1064 | 2 | 8.66 | 8.66 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.9
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:8.66
θf [deg]:8.66
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.12
θf [deg]:0.12
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-326-I-Y-A | 1064 | 2 | 0.12 | 0.12 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.12
θf [deg]:0.12
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.15
θf [deg]:0.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-327-A-Y-A | 1064 | 2 | 0.15 | 0.15 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.15
θf [deg]:0.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.36
θf [deg]:0.36
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-331-I-Y-A | 1064 | 2 | 0.36 | 0.36 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.36
θf [deg]:0.36
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:50.38
θf [deg]:50.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-332-I-Y-A | 1064 | 2 | 50.38 | 50.38 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:50.38
θf [deg]:50.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>8.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.045
θf [deg]:0.045
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<0.7 |
||||||||
DS-335-I-Y-A | 1064 | 2 | 0.045 | 0.045 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>8.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.045
θf [deg]:0.045
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<0.7 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.68
θf [deg]:0.68
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-336-I-Y-A | 1064 | 2 | 0.68 | 0.68 | 6 weeks | High Efficiency (Scan HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.68
θf [deg]:0.68
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.82
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.45
θf [deg]:0.45
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-337-I-Y-A | 1064 | 2 | 0.45 | 0.45 | 6 weeks | High Efficiency (Scan HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.82
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.45
θf [deg]:0.45
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.32
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-338-I-Y-A | 1064 | 2 | 0.32 | 0.32 | 6 weeks | High Efficiency (Scan HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.32
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.16
θf [deg]:0.16
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-339-I-Y-A | 1064 | 2 | 0.16 | 0.16 | 6 weeks | High Efficiency (Scan HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.16
θf [deg]:0.16
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:30x30
Clear Aperture [mm]:27x27
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:50.38
θf [deg]:50.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
DS-340-I-Y-A | 1064 | 2 | 50.38 | 50.38 | 8 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:30x30
Clear Aperture [mm]:27x27
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:50.38
θf [deg]:50.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.97
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.19
θf [deg]:0.19
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-341-I-Y-A | 1064 | 2 | 0.19 | 0.19 | 6 weeks | High Efficiency (CV HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.97
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.19
θf [deg]:0.19
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.85
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.20
θf [deg]:0.20
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-342-I-Y-A | 1064 | 2 | 0.20 | 0.20 | 6 weeks | High Efficiency (CV HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.85
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.20
θf [deg]:0.20
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.68
θf [deg]:0.68
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-343-I-Y-A | 1064 | 2 | 0.68 | 0.68 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.68
θf [deg]:0.68
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.52
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.24
θf [deg]:0.24
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-345-I-Y-A | 1064 | 2 | 0.24 | 0.24 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.52
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.24
θf [deg]:0.24
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>7.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.052
θf [deg]:0.052
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-346-I-Y-A | 1064 | 2 | 0.052 | 0.052 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>7.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.052
θf [deg]:0.052
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.13
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.90
θf [deg]:2.90
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-347-I-Y-A | 1064 | 2 | 2.90 | 2.90 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.13
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.90
θf [deg]:2.90
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.44
θf [deg]:2.44
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-348-I-Y-A | 1064 | 2 | 2.44 | 2.44 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:2.44
θf [deg]:2.44
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:4.88
θf [deg]:4.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
DS-349-I-Y-A | 1064 | 2 | 4.88 | 4.88 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:4.88
θf [deg]:4.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.46
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.80
θf [deg]:0.80
Transmission efficiency:Close to 100%
Overall Efficiency:~ 96
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]: |
||||||||
DS-354-I-Y-A | 1064 | 2 | 0.80 | 0.80 | 6 weeks | High Efficiency (Half Scan HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.46
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.80
θf [deg]:0.80
Transmission efficiency:Close to 100%
Overall Efficiency:~ 96
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]: |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:15
Separation Angle [deg]:0.044
θf [deg]:0.62
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:90-110% |
||||||||
MS-021-I-Y-X | 1064 | 15 | 0.044 | 0.62 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:15
Separation Angle [deg]:0.044
θf [deg]:0.62
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:90-110% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>6.46
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:15
Separation Angle [deg]:0.028
θf [deg]:0.40
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:90-110% |
||||||||
MS-022-I-Y-X | 1064 | 15 | 0.028 | 0.40 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>6.46
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:15
Separation Angle [deg]:0.028
θf [deg]:0.40
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:90-110% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.29
θf [deg]:1.72
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.6
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:80-120% |
||||||||
MS-107-I-Y-X | 1064 | 7 | 0.29 | 1.72 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.29
θf [deg]:1.72
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.6
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:80-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.57
θf [deg]:2.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.5
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-214-E-Y-A | 1064 | 6 | 0.57 | 2.86 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.57
θf [deg]:2.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.5
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.37
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.50
θf [deg]:2.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.3
Uniformity (Contrast) [%]:<7%
Zero - Order relative to
the average [%]:80-120% |
||||||||
MS-226-D-Y-X | 1064 | 5 | 0.50 | 2.00 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.37
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.50
θf [deg]:2.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.3
Uniformity (Contrast) [%]:<7%
Zero - Order relative to
the average [%]:80-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.26
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.70
θf [deg]:4.19
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.9
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:70-130% |
||||||||
MS-233-I-Y-X | 1064 | 7 | 0.70 | 4.19 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.26
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.70
θf [deg]:4.19
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.9
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:1.48
θf [deg]:10.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.3
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<2.5 |
||||||||
MS-243-E-Y-A | 1064 | 8 | 1.48 | 10.39 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:1.48
θf [deg]:10.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.3
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<2.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.76
θf [deg]:6.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.1
Uniformity (Contrast) [%]:<7%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-244-E-Y-A | 1064 | 10 | 0.76 | 6.85 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.76
θf [deg]:6.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.1
Uniformity (Contrast) [%]:<7%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.57
θf [deg]:5.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.9
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-245-E-Y-A | 1064 | 10 | 0.57 | 5.14 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.57
θf [deg]:5.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.9
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.20
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:101
Separation Angle [deg]:0.057
θf [deg]:5.73
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80.9
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:0-120% |
||||||||
MS-255-G-Y-X | 1064 | 101 | 0.057 | 5.73 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.20
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:101
Separation Angle [deg]:0.057
θf [deg]:5.73
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80.9
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:0-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.19
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:51
Separation Angle [deg]:0.057
θf [deg]:2.87
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80.5
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:0-100% |
||||||||
MS-257-I-Y-A | 1064 | 51 | 0.057 | 2.87 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.19
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:51
Separation Angle [deg]:0.057
θf [deg]:2.87
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80.5
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:0-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.22
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:19
Separation Angle [deg]:0.15
θf [deg]:2.70
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.3
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:75-130% |
||||||||
MS-268-G-Y-X | 1064 | 19 | 0.15 | 2.70 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.22
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:19
Separation Angle [deg]:0.15
θf [deg]:2.70
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.3
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:75-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.66
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19.6
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:25
Separation Angle [deg]:0.11
θf [deg]:2.64
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78.3
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:50-150% |
||||||||
MS-269-I-Y-X | 1064 | 25 | 0.11 | 2.64 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.66
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19.6
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:25
Separation Angle [deg]:0.11
θf [deg]:2.64
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78.3
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:50-150% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.26
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.70
θf [deg]:4.21
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.4
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:0-100% |
||||||||
MS-271-D-Y-A | 1064 | 7 | 0.70 | 4.21 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.26
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.70
θf [deg]:4.21
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.4
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:0-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.96
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.2
Thickness [mm]:1.5
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.19
θf [deg]:1.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.6
Uniformity (Contrast) [%]:<2%
Zero - Order relative to
the average [%]:50-100% |
||||||||
MS-272-A-Y-N | 1064 | 7 | 0.19 | 1.14 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.96
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.2
Thickness [mm]:1.5
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.19
θf [deg]:1.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.6
Uniformity (Contrast) [%]:<2%
Zero - Order relative to
the average [%]:50-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.21
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.88
θf [deg]:5.26
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.7
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:80-120% |
||||||||
MS-279-D-Y-X | 1064 | 7 | 0.88 | 5.26 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.21
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.88
θf [deg]:5.26
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.7
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:80-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.62
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.11
θf [deg]:0.91
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.8
Uniformity (Contrast) [%]:<4%
Zero - Order relative to
the average [%]:50-100% |
||||||||
MS-291-A-Y-N | 1064 | 9 | 0.11 | 0.91 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.62
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.11
θf [deg]:0.91
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.8
Uniformity (Contrast) [%]:<4%
Zero - Order relative to
the average [%]:50-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.96
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.2
Thickness [mm]:1.5
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.19
θf [deg]:1.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.2
Uniformity (Contrast) [%]:<6%
Zero - Order relative to
the average [%]:60-110% |
||||||||
MS-298-A-Y-X | 1064 | 7 | 0.19 | 1.14 | 7 weeks | Suppressed undesired orders | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.96
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.2
Thickness [mm]:1.5
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.19
θf [deg]:1.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.2
Uniformity (Contrast) [%]:<6%
Zero - Order relative to
the average [%]:60-110% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>8.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:23.76
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.045
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 72.2
Uniformity (Contrast) [%]:<1.5%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
MS-304-A-Y-A | 1064 | 8 | 0.045 | 0.32 | In Stock | Minimum Beam size 8mm | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>8.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:23.76
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.045
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 72.2
Uniformity (Contrast) [%]:<1.5%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:5.11
θf [deg]:15.37
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-307-U-Y-A | 1064 | 4 | 5.11 | 15.37 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:5.11
θf [deg]:15.37
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:11
Separation Angle [deg]:1.20
θf [deg]:12.03
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.7
Uniformity (Contrast) [%]:<4%
Zero - Order relative to
the average [%]:0-100% |
||||||||
MS-316-I-Y-A | 1064 | 11 | 1.20 | 12.03 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:11
Separation Angle [deg]:1.20
θf [deg]:12.03
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.7
Uniformity (Contrast) [%]:<4%
Zero - Order relative to
the average [%]:0-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>8.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.045
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 72.2
Uniformity (Contrast) [%]:<1.5%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
MS-320-Q-Y-A | 1064 | 8 | 0.045 | 0.32 | In Stock | Minimum Beam size 8mm | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>8.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.045
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 72.2
Uniformity (Contrast) [%]:<1.5%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:3.40
θf [deg]:10.21
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.7
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
MS-322-Q-Y-A | 1064 | 4 | 3.40 | 10.21 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:3.40
θf [deg]:10.21
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.7
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.98
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.6
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.046
θf [deg]:0.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 89.6
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:70-130% |
||||||||
MS-323-K-Y-X | 1064 | 5 | 0.046 | 0.18 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.98
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.6
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.046
θf [deg]:0.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 89.6
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:9.8x9.8
Clear Aperture [mm]:8.8x8.8
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:11
Separation Angle [deg]:1.52
θf [deg]:15.29
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.2
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:0-50% |
||||||||
MS-327-I-Y-L | 1064 | 11 | 1.52 | 15.29 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:9.8x9.8
Clear Aperture [mm]:8.8x8.8
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:11
Separation Angle [deg]:1.52
θf [deg]:15.29
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.2
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:0-50% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:19
Clear Aperture [mm]:17.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.76
θf [deg]:6.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.1
Uniformity (Contrast) [%]:<12%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
MS-331-E-Y-A | 1064 | 10 | 0.76 | 6.85 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:19
Clear Aperture [mm]:17.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.76
θf [deg]:6.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.1
Uniformity (Contrast) [%]:<12%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.37
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.00
θf [deg]:3.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 63
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
MS-332-I-Y-A | 1064 | 4 | 1.00 | 3.00 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.37
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.00
θf [deg]:3.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 63
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.76
θf [deg]:6.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.1
Uniformity (Contrast) [%]:<7%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-333-E-Y-A | 1064 | 10 | 0.76 | 6.85 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.76
θf [deg]:6.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.1
Uniformity (Contrast) [%]:<7%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.33
θf [deg]:4.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-355-J-Y-A | 1064 | 4 | 1.33 | 4.00 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.33
θf [deg]:4.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.77
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.21
θf [deg]:1.04
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-357-J-Y-A | 1064 | 6 | 0.21 | 1.04 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.77
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.21
θf [deg]:1.04
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>6.92
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.053
θf [deg]:0.16
Transmission efficiency:Close to 100%
Overall Efficiency:~ 88
Uniformity (Contrast) [%]:<8%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
MS-364-A-Y-A | 1064 | 4 | 0.053 | 0.16 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>6.92
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.053
θf [deg]:0.16
Transmission efficiency:Close to 100%
Overall Efficiency:~ 88
Uniformity (Contrast) [%]:<8%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.76
θf [deg]:3.80
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
MS-385-U-Y-A | 1064 | 6 | 0.76 | 3.80 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.76
θf [deg]:3.80
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>6.10
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.030
θf [deg]:0.24
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95.5
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:80-110% |
||||||||
MS-396-U-Y-X | 1064 | 9 | 0.030 | 0.24 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>6.10
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.030
θf [deg]:0.24
Transmission efficiency:Close to 100%
Overall Efficiency:~ 95.5
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:80-110% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.62
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.30
θf [deg]:1.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.4
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:80-120% |
||||||||
MS-398-G-Y-X | 1064 | 5 | 0.30 | 1.18 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.62
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.30
θf [deg]:1.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.4
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:80-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.55
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.14
θf [deg]:0.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-399-I-Y-A | 1064 | 4 | 0.14 | 0.43 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.55
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.14
θf [deg]:0.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.55
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.14
θf [deg]:1.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.2
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-400-I-Y-A | 1064 | 8 | 0.14 | 1.00 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.55
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.14
θf [deg]:1.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.2
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.55
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:16
Separation Angle [deg]:0.14
θf [deg]:2.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.1
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-401-I-Y-A | 1064 | 16 | 0.14 | 2.15 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.55
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:16
Separation Angle [deg]:0.14
θf [deg]:2.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.1
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.62
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.11
θf [deg]:0.91
Transmission efficiency:Close to 100%
Overall Efficiency:~ 69.7
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:50-100% |
||||||||
MS-438-I-Y-N | 1064 | 9 | 0.11 | 0.91 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.62
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.11
θf [deg]:0.91
Transmission efficiency:Close to 100%
Overall Efficiency:~ 69.7
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:50-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.42
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:15
Separation Angle [deg]:0.44
θf [deg]:6.10
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.3
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:0-100% |
||||||||
MS-454-I-Y-A | 1064 | 15 | 0.44 | 6.10 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.42
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:15
Separation Angle [deg]:0.44
θf [deg]:6.10
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.3
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:0-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:19
Separation Angle [deg]:0.38
θf [deg]:6.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.1
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:0-100% |
||||||||
MS-455-I-Y-A | 1064 | 19 | 0.38 | 6.86 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:19
Separation Angle [deg]:0.38
θf [deg]:6.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.1
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:0-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:35
Separation Angle [deg]:0.17
θf [deg]:5.92
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78.5
Uniformity (Contrast) [%]:<18%
Zero - Order relative to
the average [%]:0-100% |
||||||||
MS-456-I-Y-A | 1064 | 35 | 0.17 | 5.92 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:35
Separation Angle [deg]:0.17
θf [deg]:5.92
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78.5
Uniformity (Contrast) [%]:<18%
Zero - Order relative to
the average [%]:0-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:51
Separation Angle [deg]:0.17
θf [deg]:8.72
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.3
Uniformity (Contrast) [%]:<24%
Zero - Order relative to
the average [%]:0-100% |
||||||||
MS-457-I-Y-A | 1064 | 51 | 0.17 | 8.72 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:51
Separation Angle [deg]:0.17
θf [deg]:8.72
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.3
Uniformity (Contrast) [%]:<24%
Zero - Order relative to
the average [%]:0-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.17
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:9
Separation Angle [deg]:1.05
θf [deg]:8.42
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78.6
Uniformity (Contrast) [%]:<25%
Zero - Order relative to
the average [%]:50-150% |
||||||||
MS-453-I-Y-X | 1064 | 9 | 1.05 | 8.42 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.17
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:9
Separation Angle [deg]:1.05
θf [deg]:8.42
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78.6
Uniformity (Contrast) [%]:<25%
Zero - Order relative to
the average [%]:50-150% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13
Thickness [mm]:
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.29
θf [deg]:1.72
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.7
Uniformity (Contrast) [%]:<1.5%
Zero - Order relative to
the average [%]:60-100% |
||||||||
MS-463-I-Y-X | 1064 | 7 | 0.29 | 1.72 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13
Thickness [mm]:
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.29
θf [deg]:1.72
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.7
Uniformity (Contrast) [%]:<1.5%
Zero - Order relative to
the average [%]:60-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.7x12.7
Clear Aperture [mm]:10.9x10.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:2.43
θf [deg]:12.19
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<6%
Zero-Order relative to
the incident beam [%]:<1.8 |
||||||||
MS-473-I-Y-A | 1064 | 6 | 2.43 | 12.19 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.7x12.7
Clear Aperture [mm]:10.9x10.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:2.43
θf [deg]:12.19
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<6%
Zero-Order relative to
the incident beam [%]:<1.8 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.30
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:1.20
θf [deg]:6.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<0.7 |
||||||||
MS-474-I-Y-A | 1064 | 6 | 1.20 | 6.00 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.30
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:1.20
θf [deg]:6.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<0.7 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.91
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.40
θf [deg]:2.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
MS-475-I-Y-A | 1064 | 6 | 0.40 | 2.00 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.91
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.40
θf [deg]:2.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.18
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:1.00
θf [deg]:4.01
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.3
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:60-140% |
||||||||
MS-499-I-Y-X | 1064 | 5 | 1.00 | 4.01 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.18
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:1.00
θf [deg]:4.01
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.3
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:60-140% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:2.59
θf [deg]:12.96
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<1.8 |
||||||||
MS-501-I-Y-A | 1064 | 6 | 2.59 | 12.96 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:2.59
θf [deg]:12.96
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<1.8 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:2.59
θf [deg]:12.96
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-502-J-Y-A | 1064 | 6 | 2.59 | 12.96 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:2.59
θf [deg]:12.96
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.73
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:85
Separation Angle [deg]:0.25
θf [deg]:21.04
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.6
Uniformity (Contrast) [%]:<18%
Zero - Order relative to
the average [%]:0-150% |
||||||||
MS-505-I-Y-X | 1064 | 85 | 0.25 | 21.04 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.73
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:85
Separation Angle [deg]:0.25
θf [deg]:21.04
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.6
Uniformity (Contrast) [%]:<18%
Zero - Order relative to
the average [%]:0-150% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.73
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.50
θf [deg]:1.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.7
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-506-I-Y-A | 1064 | 4 | 0.50 | 1.50 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.73
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.50
θf [deg]:1.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.7
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:33
Separation Angle [deg]:0.036
θf [deg]:1.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.4
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:80-130% |
||||||||
MS-512-I-Y-X | 1064 | 33 | 0.036 | 1.14 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:33
Separation Angle [deg]:0.036
θf [deg]:1.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.4
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:80-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:321
Separation Angle [deg]:0.036
θf [deg]:11.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.6
Uniformity (Contrast) [%]:<45%
Zero-Order relative to
the incident beam [%]:<1.2% |
||||||||
MS-513-I-Y-X | 1064 | 321 | 0.036 | 11.39 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:321
Separation Angle [deg]:0.036
θf [deg]:11.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.6
Uniformity (Contrast) [%]:<45%
Zero-Order relative to
the incident beam [%]:<1.2% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.14
θf [deg]:0.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.3
Uniformity (Contrast) [%]:<2%
Zero - Order relative to
the average [%]:60-130% |
||||||||
MS-519-I-Y-X | 1064 | 7 | 0.14 | 0.86 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.14
θf [deg]:0.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.3
Uniformity (Contrast) [%]:<2%
Zero - Order relative to
the average [%]:60-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.084
θf [deg]:0.42
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-530-I-Y-A | 1064 | 6 | 0.084 | 0.42 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.084
θf [deg]:0.42
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.74
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.11
θf [deg]:0.42
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.4
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:80-120% |
||||||||
MS-531-I-Y-X | 1064 | 5 | 0.11 | 0.42 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.74
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.11
θf [deg]:0.42
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.4
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:80-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.61
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.070
θf [deg]:0.28
Transmission efficiency:Close to 100%
Overall Efficiency:~ 85.4
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:80-120% |
||||||||
MS-535-I-Y-X | 1064 | 5 | 0.070 | 0.28 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.61
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.070
θf [deg]:0.28
Transmission efficiency:Close to 100%
Overall Efficiency:~ 85.4
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:80-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.82
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.096
θf [deg]:0.48
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-538-I-Y-A | 1064 | 6 | 0.096 | 0.48 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.82
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.096
θf [deg]:0.48
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.53
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.12
θf [deg]:0.48
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.4
Uniformity (Contrast) [%]:<2.5%
Zero - Order relative to
the average [%]:80-120% |
||||||||
MS-539-I-Y-X | 1064 | 5 | 0.12 | 0.48 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.53
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.12
θf [deg]:0.48
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.4
Uniformity (Contrast) [%]:<2.5%
Zero - Order relative to
the average [%]:80-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.95
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:131
Separation Angle [deg]:0.062
θf [deg]:8.07
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80.7
Uniformity (Contrast) [%]:<12%
Zero - Order relative to
the average [%]:0-100% |
||||||||
MS-542-I-Y-A | 1064 | 131 | 0.062 | 8.07 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.95
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:131
Separation Angle [deg]:0.062
θf [deg]:8.07
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80.7
Uniformity (Contrast) [%]:<12%
Zero - Order relative to
the average [%]:0-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>6.78
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.054
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<1.5%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-545-I-Y-A | 1064 | 6 | 0.054 | 0.27 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>6.78
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.054
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<1.5%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x20
Clear Aperture [mm]:12x18
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.14
θf [deg]:0.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<2%
Zero - Order relative to
the average [%]:60-130% |
||||||||
MS-548-I-Y-X | 1064 | 7 | 0.14 | 0.86 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x20
Clear Aperture [mm]:12x18
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.14
θf [deg]:0.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<2%
Zero - Order relative to
the average [%]:60-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.73
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x20
Clear Aperture [mm]:12x18
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.50
θf [deg]:3.52
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.5
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-549-I-Y-A | 1064 | 8 | 0.50 | 3.52 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.73
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x20
Clear Aperture [mm]:12x18
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.50
θf [deg]:3.52
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.5
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.21
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x14
Clear Aperture [mm]:12x12
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.30
θf [deg]:2.73
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-551-I-Y-A | 1064 | 10 | 0.30 | 2.73 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.21
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:14x14
Clear Aperture [mm]:12x12
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.30
θf [deg]:2.73
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.28
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.080
θf [deg]:0.48
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:60-140% |
||||||||
MS-554-I-Y-X | 1064 | 7 | 0.080 | 0.48 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.28
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.080
θf [deg]:0.48
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:60-140% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:17x17
Clear Aperture [mm]:15.3x15.3
Thickness [mm]:0.95
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.54
θf [deg]:2.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<4%
Zero - Order relative to
the average [%]:85-115% |
||||||||
MS-555-I-Y-X | 1064 | 5 | 0.54 | 2.18 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:17x17
Clear Aperture [mm]:15.3x15.3
Thickness [mm]:0.95
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.54
θf [deg]:2.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<4%
Zero - Order relative to
the average [%]:85-115% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:17x17
Clear Aperture [mm]:15.3x15.3
Thickness [mm]:0.95
Coating:Uncoated
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.54
θf [deg]:5.44
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<4%
Zero - Order relative to
the average [%]:80-130% |
||||||||
MS-556-I-Y-X | 1064 | 11 | 0.54 | 5.44 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:17x17
Clear Aperture [mm]:15.3x15.3
Thickness [mm]:0.95
Coating:AR/AR coating
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.54
θf [deg]:5.44
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<4%
Zero - Order relative to
the average [%]:80-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.91
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.047
θf [deg]:0.28
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:60-140% |
||||||||
MS-557-I-Y-X | 1064 | 7 | 0.047 | 0.28 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.91
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.047
θf [deg]:0.28
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:60-140% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.65
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.10
θf [deg]:0.30
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.5
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-560-I-Y-A | 1064 | 4 | 0.10 | 0.30 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.65
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.10
θf [deg]:0.30
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.5
Uniformity (Contrast) [%]:<1%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.43
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:17x17
Clear Aperture [mm]:15.3x15.3
Thickness [mm]:0.95
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.42
θf [deg]:1.69
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<4%
Zero - Order relative to
the average [%]:85-115% |
||||||||
MS-572-I-Y-X | 1064 | 5 | 0.42 | 1.69 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.43
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:17x17
Clear Aperture [mm]:15.3x15.3
Thickness [mm]:0.95
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.42
θf [deg]:1.69
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<4%
Zero - Order relative to
the average [%]:85-115% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.43
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:32
Separation Angle [deg]:0.26
θf [deg]:7.95
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80.2
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-575-I-Y-A | 1064 | 32 | 0.26 | 7.95 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.43
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:32
Separation Angle [deg]:0.26
θf [deg]:7.95
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80.2
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.72
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.064
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-579-I-Y-A | 1064 | 6 | 0.064 | 0.32 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.72
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.064
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:17x17
Clear Aperture [mm]:15.3x15.3
Thickness [mm]:0.95
Coating:Uncoated
Output Parameters
Number of Spots:15
Separation Angle [deg]:0.54
θf [deg]:7.63
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.2
Uniformity (Contrast) [%]:<6%
Zero - Order relative to
the average [%]:80-120% |
||||||||
MS-580-I-Y-X | 1064 | 15 | 0.54 | 7.63 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:17x17
Clear Aperture [mm]:15.3x15.3
Thickness [mm]:0.95
Coating:AR/AR coating
Output Parameters
Number of Spots:15
Separation Angle [deg]:0.54
θf [deg]:7.63
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.2
Uniformity (Contrast) [%]:<6%
Zero - Order relative to
the average [%]:80-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.29
θf [deg]:0.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 88.9
Uniformity (Contrast) [%]:<7%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-588-I-Y-A | 1064 | 4 | 0.29 | 0.88 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.29
θf [deg]:0.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 88.9
Uniformity (Contrast) [%]:<7%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.57
θf [deg]:5.73
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:30-100% |
||||||||
MS-589-I-Y-X | 1064 | 11 | 0.57 | 5.73 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.57
θf [deg]:5.73
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:30-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.80
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.23
θf [deg]:2.29
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:30-100% |
||||||||
MS-590-I-Y-X | 1064 | 11 | 0.23 | 2.29 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.80
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.23
θf [deg]:2.29
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:30-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.60
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.11
θf [deg]:1.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:30-100% |
||||||||
MS-592-I-Y-X | 1064 | 11 | 0.11 | 1.15 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.60
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.11
θf [deg]:1.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:30-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.44
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.11
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 86.5
Uniformity (Contrast) [%]:<10%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-598-I-Y-A | 1064 | 4 | 0.11 | 0.32 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.44
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.11
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 86.5
Uniformity (Contrast) [%]:<10%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.071
θf [deg]:0.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
MS-605-I-Y-A | 1064 | 8 | 0.071 | 0.50 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.071
θf [deg]:0.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.37
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.00
θf [deg]:3.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<8%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
MS-629-I-Y-A | 1064 | 4 | 1.00 | 3.00 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.37
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.00
θf [deg]:3.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<8%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.55
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.14
θf [deg]:0.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 83
Uniformity (Contrast) [%]:<7%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
MS-630-I-Y-A | 1064 | 4 | 0.14 | 0.43 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.55
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.14
θf [deg]:0.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 83
Uniformity (Contrast) [%]:<7%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.65
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.10
θf [deg]:0.30
Transmission efficiency:Close to 100%
Overall Efficiency:~ 83
Uniformity (Contrast) [%]:<7%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
MS-631-I-Y-A | 1064 | 4 | 0.10 | 0.30 | In Stock | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.65
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.10
θf [deg]:0.30
Transmission efficiency:Close to 100%
Overall Efficiency:~ 83
Uniformity (Contrast) [%]:<7%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:3.40
θf [deg]:10.21
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<14%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-632-I-Y-A | 1064 | 4 | 3.40 | 10.21 | In Stock | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:3.40
θf [deg]:10.21
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<14%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:1.524
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.33
θf [deg]:4.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 63
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-635-I-Y-A | 1064 | 4 | 1.33 | 4.00 | 8 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:1.524
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.33
θf [deg]:4.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 63
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.28
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:1.524
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:1.33
θf [deg]:9.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.2
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-636-I-Y-A | 1064 | 8 | 1.33 | 9.32 | 8 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.28
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:1.524
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:1.33
θf [deg]:9.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.2
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.29
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:1.524
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.24
θf [deg]:3.73
Transmission efficiency:Close to 100%
Overall Efficiency:~ 63
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-647-I-Y-A | 1064 | 4 | 1.24 | 3.73 | 8 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.29
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:1.524
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.24
θf [deg]:3.73
Transmission efficiency:Close to 100%
Overall Efficiency:~ 63
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:30
Clear Aperture [mm]:27
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.071
θf [deg]:0.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
MS-665-I-Y-A | 1064 | 8 | 0.071 | 0.50 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:30
Clear Aperture [mm]:27
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.071
θf [deg]:0.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.15
θf [deg]:3.45
Transmission efficiency:Close to 100%
Overall Efficiency:~ 85
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
MS-666-I-Y-A | 1064 | 4 | 1.15 | 3.45 | In Stock | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.15
θf [deg]:3.45
Transmission efficiency:Close to 100%
Overall Efficiency:~ 85
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.63
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.58
θf [deg]:5.22
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.9
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-668-I-Y-A | 1064 | 10 | 0.58 | 5.22 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.63
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.58
θf [deg]:5.22
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.9
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.26
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.29
θf [deg]:2.61
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.9
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
MS-669-I-Y-A | 1064 | 10 | 0.29 | 2.61 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.26
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.29
θf [deg]:2.61
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.9
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.82
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:36
Clear Aperture [mm]:32.4
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.10
θf [deg]:0.80
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:0-100% |
||||||||
MS-675-I-Y-A | 1064 | 9 | 0.10 | 0.80 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.82
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:36
Clear Aperture [mm]:32.4
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.10
θf [deg]:0.80
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:0-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.62
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:36
Clear Aperture [mm]:32.4
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.23
θf [deg]:0.68
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-680-I-Y-A | 1064 | 4 | 0.23 | 0.68 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.62
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:36
Clear Aperture [mm]:32.4
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.23
θf [deg]:0.68
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.91
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:36
Clear Aperture [mm]:32.4
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.20
θf [deg]:0.80
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:80-100% |
||||||||
MS-681-I-Y-X | 1064 | 5 | 0.20 | 0.80 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.91
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:36
Clear Aperture [mm]:32.4
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.20
θf [deg]:0.80
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:80-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.21
Element Parameters
Element Type:Window
Material:Polycarbonate
Element Size [mm]:8
Clear Aperture [mm]:6.5
Thickness [mm]:0.6
Coating:Uncoated
Output Parameters
Number of Spots:501
Separation Angle [deg]:0.15
θf [deg]:82.36
Transmission efficiency:~90.2%
Overall Efficiency:~ 62.9
Uniformity (Contrast) [%]:%
Zero-Order relative to
the incident beam [%]:<2% |
||||||||
MS-683-I-N-X | 1064 | 501 | 0.15 | 82.36 | 6 weeks | Random 256 active orders | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.21
Element Parameters
Element Type:Window
Material:Polycarbonate
Element Size [mm]:8
Clear Aperture [mm]:6.5
Thickness [mm]:0.6
Coating:Uncoated
Output Parameters
Number of Spots:501
Separation Angle [deg]:0.15
θf [deg]:82.36
Transmission efficiency:~90.2%
Overall Efficiency:~ 62.9
Uniformity (Contrast) [%]:%
Zero-Order relative to
the incident beam [%]:<2% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.5
Clear Aperture [mm]:7
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:16
Separation Angle [deg]:0.57
θf [deg]:8.55
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.1
Uniformity (Contrast) [%]:<6%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-685-I-Y-A | 1064 | 16 | 0.57 | 8.55 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.5
Clear Aperture [mm]:7
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:16
Separation Angle [deg]:0.57
θf [deg]:8.55
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.1
Uniformity (Contrast) [%]:<6%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.46
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.5
Clear Aperture [mm]:7
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:16
Separation Angle [deg]:0.79
θf [deg]:11.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.1
Uniformity (Contrast) [%]:<12%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-686-I-Y-A | 1064 | 16 | 0.79 | 11.86 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.46
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.5
Clear Aperture [mm]:7
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:16
Separation Angle [deg]:0.79
θf [deg]:11.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.1
Uniformity (Contrast) [%]:<12%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Polycarbonate
Element Size [mm]:8
Clear Aperture [mm]:6.5
Thickness [mm]:0.6
Coating:Uncoated
Output Parameters
Number of Spots:201
Separation Angle [deg]:0.38
θf [deg]:82.36
Transmission efficiency:~90.2%
Overall Efficiency:~ 62.9
Uniformity (Contrast) [%]:%
Zero-Order relative to
the incident beam [%]:<2% |
||||||||
MS-687-I-N-X | 1064 | 201 | 0.38 | 82.36 | 6 weeks | Random 100 active orders | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Polycarbonate
Element Size [mm]:8
Clear Aperture [mm]:6.5
Thickness [mm]:0.6
Coating:Uncoated
Output Parameters
Number of Spots:201
Separation Angle [deg]:0.38
θf [deg]:82.36
Transmission efficiency:~90.2%
Overall Efficiency:~ 62.9
Uniformity (Contrast) [%]:%
Zero-Order relative to
the incident beam [%]:<2% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.85
Element Parameters
Element Type:Window
Material:Polycarbonate
Element Size [mm]:8
Clear Aperture [mm]:6.5
Thickness [mm]:0.6
Coating:Uncoated
Output Parameters
Number of Spots:351
Separation Angle [deg]:0.22
θf [deg]:82.36
Transmission efficiency:~90.2%
Overall Efficiency:~ 62.9
Uniformity (Contrast) [%]:%
Zero-Order relative to
the incident beam [%]:<2% |
||||||||
MS-688-I-N-X | 1064 | 351 | 0.22 | 82.36 | 6 weeks | Random 178 active orders | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.85
Element Parameters
Element Type:Window
Material:Polycarbonate
Element Size [mm]:8
Clear Aperture [mm]:6.5
Thickness [mm]:0.6
Coating:Uncoated
Output Parameters
Number of Spots:351
Separation Angle [deg]:0.22
θf [deg]:82.36
Transmission efficiency:~90.2%
Overall Efficiency:~ 62.9
Uniformity (Contrast) [%]:%
Zero-Order relative to
the incident beam [%]:<2% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:32
Separation Angle [deg]:0.085
θf [deg]:2.63
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.2
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
MS-690-I-Y-A | 1064 | 32 | 0.085 | 2.63 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:32
Separation Angle [deg]:0.085
θf [deg]:2.63
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.2
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.24
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:32
Separation Angle [deg]:0.11
θf [deg]:3.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.2
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
MS-704-I-Y-A | 1064 | 32 | 0.11 | 3.50 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.24
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:32
Separation Angle [deg]:0.11
θf [deg]:3.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.2
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.81
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:33
Separation Angle [deg]:0.22
θf [deg]:7.20
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81
Uniformity (Contrast) [%]:<6%
Zero - Order relative to
the average [%]:70-150% |
||||||||
MS-705-I-Y-X | 1064 | 33 | 0.22 | 7.20 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.81
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:33
Separation Angle [deg]:0.22
θf [deg]:7.20
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81
Uniformity (Contrast) [%]:<6%
Zero - Order relative to
the average [%]:70-150% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.95
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:18
Separation Angle [deg]:0.061
θf [deg]:1.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 94
Uniformity (Contrast) [%]:<10%
Zero-Order relative to
the incident beam [%]:<0.2 |
||||||||
MS-707-I-Y-A | 1064 | 18 | 0.061 | 1.05 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.95
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:18
Separation Angle [deg]:0.061
θf [deg]:1.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 94
Uniformity (Contrast) [%]:<10%
Zero-Order relative to
the incident beam [%]:<0.2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.94
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:18
Separation Angle [deg]:0.062
θf [deg]:1.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
MS-709-I-Y-A | 1064 | 18 | 0.062 | 1.05 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.94
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:18
Separation Angle [deg]:0.062
θf [deg]:1.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>9.52
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:24
Separation Angle [deg]:0.038
θf [deg]:0.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
MS-710-I-Y-A | 1064 | 24 | 0.038 | 0.88 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>9.52
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:24
Separation Angle [deg]:0.038
θf [deg]:0.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:8
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:1.52
θf [deg]:9.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.6
Uniformity (Contrast) [%]:<6%
Zero - Order relative to
the average [%]:50-120% |
||||||||
MS-716-I-Y-X | 1064 | 7 | 1.52 | 9.14 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:8
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:1.52
θf [deg]:9.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.6
Uniformity (Contrast) [%]:<6%
Zero - Order relative to
the average [%]:50-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:13
Separation Angle [deg]:0.060
θf [deg]:0.71
Transmission efficiency:Close to 100%
Overall Efficiency:~ 91.6
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:75-115% |
||||||||
MS-718-I-Y-X | 1064 | 13 | 0.060 | 0.71 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:13
Separation Angle [deg]:0.060
θf [deg]:0.71
Transmission efficiency:Close to 100%
Overall Efficiency:~ 91.6
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:75-115% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.78
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.10
θf [deg]:0.82
Transmission efficiency:Close to 100%
Overall Efficiency:~ 93
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:90-110% |
||||||||
MS-721-I-Y-X | 1064 | 9 | 0.10 | 0.82 | In Stock | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.78
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.10
θf [deg]:0.82
Transmission efficiency:Close to 100%
Overall Efficiency:~ 93
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:90-110% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.30
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:14
Separation Angle [deg]:1.23
θf [deg]:16.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<8%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
MS-731-I-Y-A | 1064 | 14 | 1.23 | 16.00 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.30
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:14
Separation Angle [deg]:1.23
θf [deg]:16.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<8%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>15.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.024
θf [deg]:0.12
Transmission efficiency:Close to 100%
Overall Efficiency:~ 87.5
Uniformity (Contrast) [%]:<6%
Zero-Order relative to
the incident beam [%]:<0.2 |
||||||||
MS-734-I-Y-A | 1064 | 6 | 0.024 | 0.12 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>15.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.024
θf [deg]:0.12
Transmission efficiency:Close to 100%
Overall Efficiency:~ 87.5
Uniformity (Contrast) [%]:<6%
Zero-Order relative to
the incident beam [%]:<0.2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.10
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.7
Clear Aperture [mm]:9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:17
Separation Angle [deg]:0.087
θf [deg]:1.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:75-100% |
||||||||
MS-735-I-Y-X | 1064 | 17 | 0.087 | 1.39 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.10
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.7
Clear Aperture [mm]:9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:17
Separation Angle [deg]:0.087
θf [deg]:1.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:75-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.81
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:17
Separation Angle [deg]:0.22
θf [deg]:3.60
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:60-110% |
||||||||
MS-736-I-Y-X | 1064 | 17 | 0.22 | 3.60 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.81
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:17
Separation Angle [deg]:0.22
θf [deg]:3.60
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:60-110% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.82
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.096
θf [deg]:0.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 91
Uniformity (Contrast) [%]:<10%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
MS-738-I-Y-A | 1064 | 8 | 0.096 | 0.67 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.82
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.096
θf [deg]:0.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 91
Uniformity (Contrast) [%]:<10%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.57
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.5
Clear Aperture [mm]:7
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:16
Separation Angle [deg]:0.64
θf [deg]:9.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<0.7 |
||||||||
MS-739-I-Y-A | 1064 | 16 | 0.64 | 9.67 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.57
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12.5
Clear Aperture [mm]:7
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:16
Separation Angle [deg]:0.64
θf [deg]:9.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<0.7 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.66
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:65.1
Clear Aperture [mm]:58.6
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 97
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<0.2 |
||||||||
MS-740-I-Y-A | 1064 | 2 | 0.14 | 0.14 | In Stock | High Efficiency (Half Scan HEDS) | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.66
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:65.1
Clear Aperture [mm]:58.6
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:2
Separation Angle [deg]:0.14
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 97
Uniformity (Contrast) [%]:Alignment dependent
Zero-Order relative to
the incident beam [%]:<0.2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>10.72
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.017
θf [deg]:0.10
Transmission efficiency:Close to 100%
Overall Efficiency:~ 87
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:85-115% |
||||||||
MS-768-I-Y-X | 1064 | 7 | 0.017 | 0.10 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>10.72
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.017
θf [deg]:0.10
Transmission efficiency:Close to 100%
Overall Efficiency:~ 87
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:85-115% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.46
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:16
Separation Angle [deg]:0.25
θf [deg]:3.77
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
MS-770-I-Y-A | 1064 | 16 | 0.25 | 3.77 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.46
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:16
Separation Angle [deg]:0.25
θf [deg]:3.77
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.62
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.23
θf [deg]:0.68
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-772-I-Y-A | 1064 | 4 | 0.23 | 0.68 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.62
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.23
θf [deg]:0.68
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.056
θf [deg]:0.45
Transmission efficiency:Close to 100%
Overall Efficiency:~ 96
Uniformity (Contrast) [%]:<6%
Zero - Order relative to
the average [%]:80-120% |
||||||||
MS-777-I-Y-X | 1064 | 9 | 0.056 | 0.45 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.056
θf [deg]:0.45
Transmission efficiency:Close to 100%
Overall Efficiency:~ 96
Uniformity (Contrast) [%]:<6%
Zero - Order relative to
the average [%]:80-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.61
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:33
Separation Angle [deg]:0.11
θf [deg]:3.64
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:70-150% |
||||||||
MS-778-I-Y-X | 1064 | 33 | 0.11 | 3.64 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.61
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:33
Separation Angle [deg]:0.11
θf [deg]:3.64
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:70-150% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.55
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.8
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.14
θf [deg]:1.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 93
Uniformity (Contrast) [%]:<9%
Zero-Order relative to
the incident beam [%]:<0.2 |
||||||||
MS-780-I-Y-A | 1064 | 8 | 0.14 | 1.00 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.55
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.8
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.14
θf [deg]:1.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 93
Uniformity (Contrast) [%]:<9%
Zero-Order relative to
the incident beam [%]:<0.2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.41
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:33
Separation Angle [deg]:0.076
θf [deg]:2.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:85-135% |
||||||||
MS-781-I-Y-X | 1064 | 33 | 0.076 | 2.43 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.41
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:33
Separation Angle [deg]:0.076
θf [deg]:2.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:85-135% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.80
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.23
θf [deg]:2.29
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:30-100% |
||||||||
MS-786-I-Y-X | 1064 | 11 | 0.23 | 2.29 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.80
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20x20
Clear Aperture [mm]:18x18
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.23
θf [deg]:2.29
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:30-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.28
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:1.33
θf [deg]:9.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.2
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-787-I-Y-A | 1064 | 8 | 1.33 | 9.32 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.28
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:1.33
θf [deg]:9.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.2
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.071
θf [deg]:0.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
MS-793-I-Y-A | 1064 | 8 | 0.071 | 0.50 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.071
θf [deg]:0.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 73.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:50
Separation Angle [deg]:0.27
θf [deg]:13.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.6
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
MS-802-I-Y-A | 1064 | 50 | 0.27 | 13.43 | 8 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:50
Separation Angle [deg]:0.27
θf [deg]:13.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.6
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.056
θf [deg]:0.22
Transmission efficiency:Close to 100%
Overall Efficiency:~ 89
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:90-110% |
||||||||
MS-809-I-Y-X | 1064 | 5 | 0.056 | 0.22 | In Stock | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.056
θf [deg]:0.22
Transmission efficiency:Close to 100%
Overall Efficiency:~ 89
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:90-110% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:30
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.91
θf [deg]:4.53
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-811-I-Y-A | 1064 | 6 | 0.91 | 4.53 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:30
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.91
θf [deg]:4.53
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>6.53
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:49
Separation Angle [deg]:0.028
θf [deg]:1.34
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:60-130% |
||||||||
MS-813-I-Y-X | 1064 | 49 | 0.028 | 1.34 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>6.53
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:49
Separation Angle [deg]:0.028
θf [deg]:1.34
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:60-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>13.06
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:50
Separation Angle [deg]:0.028
θf [deg]:1.37
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-814-I-Y-A | 1064 | 50 | 0.028 | 1.37 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>13.06
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:50
Separation Angle [deg]:0.028
θf [deg]:1.37
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:25
Separation Angle [deg]:0.14
θf [deg]:3.28
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.9
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:70-160% |
||||||||
MS-816-I-Y-X | 1064 | 25 | 0.14 | 3.28 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:25
Separation Angle [deg]:0.14
θf [deg]:3.28
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.9
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:70-160% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.19
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.96
θf [deg]:9.66
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.4
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:50-150% |
||||||||
MS-818-I-Y-X | 1064 | 11 | 0.96 | 9.66 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.19
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.96
θf [deg]:9.66
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.4
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:50-150% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.19
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.96
θf [deg]:7.72
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78.7
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:50-150% |
||||||||
MS-819-I-Y-X | 1064 | 9 | 0.96 | 7.72 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.19
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:9
Separation Angle [deg]:0.96
θf [deg]:7.72
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78.7
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:50-150% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.19
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.95
θf [deg]:5.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.8
Uniformity (Contrast) [%]:<6%
Zero - Order relative to
the average [%]:50-120% |
||||||||
MS-820-I-Y-X | 1064 | 7 | 0.95 | 5.67 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.19
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.95
θf [deg]:5.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76.8
Uniformity (Contrast) [%]:<6%
Zero - Order relative to
the average [%]:50-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:19
Separation Angle [deg]:0.38
θf [deg]:6.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.1
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:0-100% |
||||||||
MS-830-I-Y-A | 1064 | 19 | 0.38 | 6.86 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.48
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:19
Separation Angle [deg]:0.38
θf [deg]:6.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.1
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:0-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>12.23
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.030
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-834-I-Y-A | 1064 | 10 | 0.030 | 0.27 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>12.23
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.030
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.24
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.50
θf [deg]:4.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.3
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-843-I-Y-A | 1064 | 4 | 1.50 | 4.50 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.24
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.50
θf [deg]:4.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.3
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.36
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:1.01
θf [deg]:5.07
Transmission efficiency:Close to 100%
Overall Efficiency:~ 83
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-855-I-Y-A | 1064 | 6 | 1.01 | 5.07 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.36
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:1.01
θf [deg]:5.07
Transmission efficiency:Close to 100%
Overall Efficiency:~ 83
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.72
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.064
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-869-I-Y-A | 1064 | 6 | 0.064 | 0.32 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.72
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.064
θf [deg]:0.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.95
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:131
Separation Angle [deg]:0.062
θf [deg]:8.07
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80.7
Uniformity (Contrast) [%]:<12%
Zero - Order relative to
the average [%]:0-100% |
||||||||
MS-871-I-Y-A | 1064 | 131 | 0.062 | 8.07 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.95
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:131
Separation Angle [deg]:0.062
θf [deg]:8.07
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80.7
Uniformity (Contrast) [%]:<12%
Zero - Order relative to
the average [%]:0-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:129
Separation Angle [deg]:0.16
θf [deg]:20.49
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.5
Uniformity (Contrast) [%]:<30%
Zero-Order relative to
the incident beam [%]:<1% |
||||||||
MS-872-I-Y-X | 1064 | 129 | 0.16 | 20.49 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:129
Separation Angle [deg]:0.16
θf [deg]:20.49
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.5
Uniformity (Contrast) [%]:<30%
Zero-Order relative to
the incident beam [%]:<1% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>13.88
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.026
θf [deg]:0.079
Transmission efficiency:Close to 100%
Overall Efficiency:~ 90
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<0.3 |
||||||||
MS-873-I-Y-A | 1064 | 4 | 0.026 | 0.079 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>13.88
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.026
θf [deg]:0.079
Transmission efficiency:Close to 100%
Overall Efficiency:~ 90
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<0.3 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.24
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.75
θf [deg]:3.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 87
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:90-100% |
||||||||
MS-876-I-Y-X | 1064 | 5 | 0.75 | 3.00 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.24
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.75
θf [deg]:3.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 87
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:90-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:41
Separation Angle [deg]:0.046
θf [deg]:1.82
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:75-125% |
||||||||
MS-881-I-Y-X | 1064 | 41 | 0.046 | 1.82 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:41
Separation Angle [deg]:0.046
θf [deg]:1.82
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:75-125% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>8.03
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.046
θf [deg]:0.41
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-882-I-Y-A | 1064 | 10 | 0.046 | 0.41 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>8.03
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.046
θf [deg]:0.41
Transmission efficiency:Close to 100%
Overall Efficiency:~ 76
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.91
θf [deg]:4.53
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-883-I-Y-A | 1064 | 6 | 0.91 | 4.53 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:6
Separation Angle [deg]:0.91
θf [deg]:4.53
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82.5
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.33
θf [deg]:4.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
MS-884-I-Y-A | 1064 | 4 | 1.33 | 4.00 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.33
θf [deg]:4.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:32
Thickness [mm]:3.5
Coating:Uncoated
Output Parameters
Number of Spots:15
Separation Angle [deg]:2.45
θf [deg]:34.75
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<25%
Zero - Order relative to
the average [%]:50-200% |
||||||||
MS-885-I-Y-X | 1064 | 15 | 2.45 | 34.75 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:32
Thickness [mm]:3.5
Coating:AR/AR coating
Output Parameters
Number of Spots:15
Separation Angle [deg]:2.45
θf [deg]:34.75
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<25%
Zero - Order relative to
the average [%]:50-200% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.82
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.22
θf [deg]:1.34
Transmission efficiency:Close to 100%
Overall Efficiency:~ 94
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:90-110% |
||||||||
MS-886-I-Y-X | 1064 | 7 | 0.22 | 1.34 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.82
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:7
Separation Angle [deg]:0.22
θf [deg]:1.34
Transmission efficiency:Close to 100%
Overall Efficiency:~ 94
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:90-110% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.37
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.99
θf [deg]:8.91
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-890-I-Y-A | 1064 | 10 | 0.99 | 8.91 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.37
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:10
Separation Angle [deg]:0.99
θf [deg]:8.91
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:10
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:75
Separation Angle [deg]:0.54
θf [deg]:40.78
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<20%
Zero - Order relative to
the average [%]:0-150% |
||||||||
MS-891-I-Y-X | 1064 | 75 | 0.54 | 40.78 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:10
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:75
Separation Angle [deg]:0.54
θf [deg]:40.78
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<20%
Zero - Order relative to
the average [%]:0-150% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.56
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.23
θf [deg]:0.70
Transmission efficiency:Close to 100%
Overall Efficiency:~ 87
Uniformity (Contrast) [%]:<6%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
MS-893-I-Y-A | 1064 | 4 | 0.23 | 0.70 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.56
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.23
θf [deg]:0.70
Transmission efficiency:Close to 100%
Overall Efficiency:~ 87
Uniformity (Contrast) [%]:<6%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.91
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.20
θf [deg]:0.80
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:80-100% |
||||||||
MS-899-I-Y-X | 1064 | 5 | 0.20 | 0.80 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.91
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.20
θf [deg]:0.80
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75
Uniformity (Contrast) [%]:<3%
Zero - Order relative to
the average [%]:80-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.46
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:16
Separation Angle [deg]:0.79
θf [deg]:11.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.1
Uniformity (Contrast) [%]:<12%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-904-I-Y-A | 1064 | 16 | 0.79 | 11.86 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.46
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:16
Separation Angle [deg]:0.79
θf [deg]:11.86
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.1
Uniformity (Contrast) [%]:<12%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.57
θf [deg]:5.73
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:30-100% |
||||||||
MS-907-I-Y-X | 1064 | 11 | 0.57 | 5.73 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.32
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:11
Separation Angle [deg]:0.57
θf [deg]:5.73
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<5%
Zero - Order relative to
the average [%]:30-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:10
Separation Angle [deg]:1.48
θf [deg]:13.36
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.7
Uniformity (Contrast) [%]:<8%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-912-I-Y-A | 1064 | 10 | 1.48 | 13.36 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:10
Separation Angle [deg]:1.48
θf [deg]:13.36
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.7
Uniformity (Contrast) [%]:<8%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.86
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.047
θf [deg]:0.19
Transmission efficiency:Close to 100%
Overall Efficiency:~ 86
Uniformity (Contrast) [%]:<7%
Zero - Order relative to
the average [%]:90-110% |
||||||||
MS-923-I-Y-X | 1064 | 5 | 0.047 | 0.19 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.86
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.047
θf [deg]:0.19
Transmission efficiency:Close to 100%
Overall Efficiency:~ 86
Uniformity (Contrast) [%]:<7%
Zero - Order relative to
the average [%]:90-110% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.42
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:15
Separation Angle [deg]:0.44
θf [deg]:6.10
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80.5
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:0-100% |
||||||||
MS-926-I-Y-A | 1064 | 15 | 0.44 | 6.10 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.42
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:15
Separation Angle [deg]:0.44
θf [deg]:6.10
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80.5
Uniformity (Contrast) [%]:<8%
Zero - Order relative to
the average [%]:0-100% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:4.49
θf [deg]:13.51
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<1.25 |
||||||||
MS-929-I-Y-A | 1064 | 4 | 4.49 | 13.51 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:4.49
θf [deg]:13.51
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<4%
Zero-Order relative to
the incident beam [%]:<1.25 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>8.63
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:40
Separation Angle [deg]:0.042
θf [deg]:1.65
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
MS-960-I-Y-A | 1064 | 40 | 0.042 | 1.65 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>8.63
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:40
Separation Angle [deg]:0.042
θf [deg]:1.65
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<0.6 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.39
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:24
Separation Angle [deg]:0.93
θf [deg]:21.55
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.7
Uniformity (Contrast) [%]:<6%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
MS-961-I-Y-A | 1064 | 24 | 0.93 | 21.55 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.39
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:24
Separation Angle [deg]:0.93
θf [deg]:21.55
Transmission efficiency:Close to 100%
Overall Efficiency:~ 79.7
Uniformity (Contrast) [%]:<6%
Zero-Order relative to
the incident beam [%]:<1.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.21
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.72
θf [deg]:5.16
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-965-I-Y-A | 1064 | 4 | 1.72 | 5.16 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.21
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:1.72
θf [deg]:5.16
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.16
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:2.29
θf [deg]:6.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-966-I-Y-A | 1064 | 4 | 2.29 | 6.88 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.16
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:2.29
θf [deg]:6.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 68.6
Uniformity (Contrast) [%]:<2%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:1.35
θf [deg]:5.40
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:90-110% |
||||||||
MS-982-I-Y-X | 1064 | 5 | 1.35 | 5.40 | In Stock | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:1.35
θf [deg]:5.40
Transmission efficiency:Close to 100%
Overall Efficiency:~ 82
Uniformity (Contrast) [%]:<10%
Zero - Order relative to
the average [%]:90-110% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>6.92
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.053
θf [deg]:0.16
Transmission efficiency:Close to 100%
Overall Efficiency:~ 88
Uniformity (Contrast) [%]:<8%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
MS-995-I-Y-A | 1064 | 4 | 0.053 | 0.16 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>6.92
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:4
Separation Angle [deg]:0.053
θf [deg]:0.16
Transmission efficiency:Close to 100%
Overall Efficiency:~ 88
Uniformity (Contrast) [%]:<8%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12
Clear Aperture [mm]:10.8
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:50
Separation Angle [deg]:0.36
θf [deg]:17.71
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-996-I-Y-A | 1064 | 50 | 0.36 | 17.71 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12
Clear Aperture [mm]:10.8
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:50
Separation Angle [deg]:0.36
θf [deg]:17.71
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.82
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.096
θf [deg]:0.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 91
Uniformity (Contrast) [%]:<10%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
MS-997-I-Y-A | 1064 | 8 | 0.096 | 0.67 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.82
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.096
θf [deg]:0.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 91
Uniformity (Contrast) [%]:<10%
Zero-Order relative to
the incident beam [%]:<0.5 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:44
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:15
Separation Angle [deg]:2.45
θf [deg]:34.75
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<25%
Zero - Order relative to
the average [%]:50-200% |
||||||||
MS-998-I-Y-X | 1064 | 15 | 2.45 | 34.75 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:44
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:15
Separation Angle [deg]:2.45
θf [deg]:34.75
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<25%
Zero - Order relative to
the average [%]:50-200% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.76
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:12
Separation Angle [deg]:0.48
θf [deg]:5.28
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-999-I-Y-A | 1064 | 12 | 0.48 | 5.28 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.76
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:12
Separation Angle [deg]:0.48
θf [deg]:5.28
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.57
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:65
Separation Angle [deg]:0.32
θf [deg]:20.47
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<25%
Zero - Order relative to
the average [%]:0-120% |
||||||||
MS-1000-I-Y-X | 1064 | 65 | 0.32 | 20.47 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.57
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:65
Separation Angle [deg]:0.32
θf [deg]:20.47
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<25%
Zero - Order relative to
the average [%]:0-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.55
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45.7
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.14
θf [deg]:1.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.2
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
MS-1002-I-Y-A | 1064 | 8 | 0.14 | 1.00 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.55
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45.7
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:8
Separation Angle [deg]:0.14
θf [deg]:1.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 74.2
Uniformity (Contrast) [%]:<3%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:92
Separation Angle [deg]:0.27
θf [deg]:25.10
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81
Uniformity (Contrast) [%]:<8%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Ms-1006-I-Y-A | 1064 | 92 | 0.27 | 25.10 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.34
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:92
Separation Angle [deg]:0.27
θf [deg]:25.10
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81
Uniformity (Contrast) [%]:<8%
Zero-Order relative to
the incident beam [%]:<1 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.53
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.12
θf [deg]:0.48
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.4
Uniformity (Contrast) [%]:<2.5%
Zero - Order relative to
the average [%]:80-120% |
||||||||
MS-1008-I-Y-X | 1064 | 5 | 0.12 | 0.48 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.53
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:5
Separation Angle [deg]:0.12
θf [deg]:0.48
Transmission efficiency:Close to 100%
Overall Efficiency:~ 75.4
Uniformity (Contrast) [%]:<2.5%
Zero - Order relative to
the average [%]:80-120% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.09
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:32
Thickness [mm]:3.5
Coating:Uncoated
Output Parameters
Number of Spots:15
Separation Angle [deg]:1.96
θf [deg]:27.64
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<25%
Zero - Order relative to
the average [%]:50-200% |
||||||||
MS-1011-I-Y-X | 1064 | 15 | 1.96 | 27.64 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.09
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:32
Thickness [mm]:3.5
Coating:AR/AR coating
Output Parameters
Number of Spots:15
Separation Angle [deg]:1.96
θf [deg]:27.64
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<25%
Zero - Order relative to
the average [%]:50-200% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.31
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:30
Separation Angle [deg]:1.19
θf [deg]:35.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<6%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
MS-1012-I-Y-A | 1064 | 30 | 1.19 | 35.05 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.31
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:30
Separation Angle [deg]:1.19
θf [deg]:35.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 78
Uniformity (Contrast) [%]:<6%
Zero-Order relative to
the incident beam [%]:<2 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:15
Separation Angle [deg]:2.47
θf [deg]:35.06
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<20%
Zero - Order relative to
the average [%]:30-250% |
||||||||
MS-1013-I-Y-X | 1064 | 15 | 2.47 | 35.06 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:15
Separation Angle [deg]:2.47
θf [deg]:35.06
Transmission efficiency:Close to 100%
Overall Efficiency:~ 80
Uniformity (Contrast) [%]:<20%
Zero - Order relative to
the average [%]:30-250% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:60
Separation Angle [deg]:0.22
θf [deg]:13.17
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.7
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
MS-1016-I-Y-A | 1064 | 60 | 0.22 | 13.17 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.64
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:60
Separation Angle [deg]:0.22
θf [deg]:13.17
Transmission efficiency:Close to 100%
Overall Efficiency:~ 81.7
Uniformity (Contrast) [%]:<5%
Zero-Order relative to
the incident beam [%]:<0.8 |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.068
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-003-A-Y-A | 1064 | 3 | 0.068 | 0.14 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.068
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.14
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-004-A-Y-A | 1064 | 3 | 0.14 | 0.27 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.14
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.27
θf [deg]:2.54
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-008-I-Y-A | 1064 | 3 | 1.27 | 2.54 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.27
θf [deg]:2.54
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:10.21
θf [deg]:20.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-015-I-Y-A | 1064 | 3 | 10.21 | 20.43 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:10.21
θf [deg]:20.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.72
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.032
θf [deg]:0.064
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-016-I-Y-A | 1064 | 3 | 0.032 | 0.064 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>5.72
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.032
θf [deg]:0.064
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.076
θf [deg]:0.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-027-A-Y-A | 1064 | 3 | 0.076 | 0.15 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.076
θf [deg]:0.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.69
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.050
θf [deg]:0.099
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-028-A-Y-A | 1064 | 3 | 0.050 | 0.099 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.69
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.050
θf [deg]:0.099
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:10.00
θf [deg]:20.01
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-030-I-Y-A | 1064 | 3 | 10.00 | 20.01 | 7 weeks | Cut-Off 1mm | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:10.00
θf [deg]:20.01
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:5.09
θf [deg]:10.17
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-031-I-Y-A | 1064 | 3 | 5.09 | 10.17 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:5.09
θf [deg]:10.17
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.53
θf [deg]:1.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-200-C-Y-A | 1064 | 3 | 0.53 | 1.05 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.53
θf [deg]:1.05
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.38
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.48
θf [deg]:0.96
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-201-A-Y-A | 1064 | 3 | 0.48 | 0.96 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.38
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.48
θf [deg]:0.96
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:18
Clear Aperture [mm]:16.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:10.00
θf [deg]:20.01
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-202-I-Y-A | 1064 | 3 | 10.00 | 20.01 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:18
Clear Aperture [mm]:16.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:10.00
θf [deg]:20.01
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.14
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-203-I-Y-A | 1064 | 3 | 0.14 | 0.27 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.14
θf [deg]:0.27
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.44
θf [deg]:4.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-204-U-Y-A | 1064 | 3 | 2.44 | 4.88 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.44
θf [deg]:4.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.091
θf [deg]:0.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-205-A-Y-A | 1064 | 3 | 0.091 | 0.18 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.091
θf [deg]:0.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:10600
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.00
Element Parameters
Element Type:Lens
Material:ZnSe
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:2.5
Radius of Curvature [mm]:112.6
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:1 mm
θf [deg]:2mm
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-208-A-Y-A | 10600 | 3 | 1 mm | 2mm | In Stock | Lens PLCX BFL=80mm, Notch | ||
Input Parameters
Wavelength [nm]:10600
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.00
Element Parameters
Element Type:Lens
Material:ZnSe
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:2.5
Radius of Curvature [mm]:112.6
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:1 mm
θf [deg]:2mm
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:15.43
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:50-200% |
||||||||
TS-210-Q-Y-A | 1064 | 3 | 15.43 | 30.85 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:15.43
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:50-200% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:3.81
θf [deg]:7.63
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-211-I-Y-A | 1064 | 3 | 3.81 | 7.63 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:3.81
θf [deg]:7.63
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:4.36
θf [deg]:8.72
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-212-I-Y-A | 1064 | 3 | 4.36 | 8.72 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:4.36
θf [deg]:8.72
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.54
θf [deg]:5.08
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-213-I-Y-A | 1064 | 3 | 2.54 | 5.08 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.07
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.54
θf [deg]:5.08
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.46
θf [deg]:0.92
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-216-G-Y-A | 1064 | 3 | 0.46 | 0.92 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.46
θf [deg]:0.92
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:9.8x9.8
Clear Aperture [mm]:8.8x8.8
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:7.64
θf [deg]:15.29
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-220-X-Y-A | 1064 | 3 | 7.64 | 15.29 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:9.8x9.8
Clear Aperture [mm]:8.8x8.8
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:7.64
θf [deg]:15.29
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.46
θf [deg]:0.92
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-224-G-Y-A | 1064 | 3 | 0.46 | 0.92 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.46
θf [deg]:0.92
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.7
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.072
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-225-Q-Y-A | 1064 | 3 | 0.072 | 0.14 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.7
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.072
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.73
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.2
Thickness [mm]:1.5
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.25
θf [deg]:0.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-230-A-Y-A | 1064 | 3 | 0.25 | 0.50 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.73
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.2
Thickness [mm]:1.5
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.25
θf [deg]:0.50
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.34
θf [deg]:0.68
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-232-I-Y-A | 1064 | 3 | 0.34 | 0.68 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.34
θf [deg]:0.68
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.03
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:7.19
θf [deg]:14.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-233-I-Y-A | 1064 | 3 | 7.19 | 14.38 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.03
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:7.19
θf [deg]:14.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12x12
Clear Aperture [mm]:10.8x10.8
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:15.43
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-234-I-Y-A | 1064 | 3 | 15.43 | 30.85 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:12x12
Clear Aperture [mm]:10.8x10.8
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:15.43
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.09
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.07
θf [deg]:4.13
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-235-I-Y-A | 1064 | 3 | 2.07 | 4.13 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.09
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.07
θf [deg]:4.13
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.10
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.83
θf [deg]:3.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-236-I-Y-A | 1064 | 3 | 1.83 | 3.67 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.10
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.83
θf [deg]:3.67
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.69
θf [deg]:3.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-237-I-Y-A | 1064 | 3 | 1.69 | 3.39 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.69
θf [deg]:3.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.69
θf [deg]:3.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-238-I-Y-A | 1064 | 3 | 1.69 | 3.39 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.11
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.69
θf [deg]:3.39
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.56
θf [deg]:3.13
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-239-I-Y-A | 1064 | 3 | 1.56 | 3.13 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.56
θf [deg]:3.13
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.13
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.45
θf [deg]:2.90
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-240-I-Y-A | 1064 | 3 | 1.45 | 2.90 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.13
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.45
θf [deg]:2.90
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.35
θf [deg]:2.71
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-241-I-Y-A | 1064 | 3 | 1.35 | 2.71 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.35
θf [deg]:2.71
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.22
θf [deg]:2.44
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-242-I-Y-A | 1064 | 3 | 1.22 | 2.44 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.15
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15x15
Clear Aperture [mm]:13.5x13.5
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.22
θf [deg]:2.44
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.17
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.09
θf [deg]:2.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-243-I-Y-A | 1064 | 3 | 1.09 | 2.18 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.17
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.09
θf [deg]:2.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.67
θf [deg]:1.35
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-245-I-Y-A | 1064 | 3 | 0.67 | 1.35 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.67
θf [deg]:1.35
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.67
θf [deg]:1.35
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-246-I-Y-A | 1064 | 3 | 0.67 | 1.35 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.27
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.67
θf [deg]:1.35
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.15
θf [deg]:0.29
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-247-I-Y-A | 1064 | 3 | 0.15 | 0.29 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.25
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.15
θf [deg]:0.29
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.43
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.13
θf [deg]:0.25
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-248-I-Y-A | 1064 | 3 | 0.13 | 0.25 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.43
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.13
θf [deg]:0.25
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.49
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.073
θf [deg]:0.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-249-I-Y-A | 1064 | 3 | 0.073 | 0.15 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.49
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:11
Clear Aperture [mm]:9.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.073
θf [deg]:0.15
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.072
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-250-I-Y-A | 1064 | 3 | 0.072 | 0.14 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.54
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.072
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.059
θf [deg]:0.12
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-251-I-Y-A | 1064 | 3 | 0.059 | 0.12 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.12
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.059
θf [deg]:0.12
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.91
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.047
θf [deg]:0.094
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-252-I-Y-A | 1064 | 3 | 0.047 | 0.094 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.91
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.047
θf [deg]:0.094
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.79
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.038
θf [deg]:0.076
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-253-I-Y-A | 1064 | 3 | 0.038 | 0.076 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.79
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.038
θf [deg]:0.076
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>9.69
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.019
θf [deg]:0.038
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-254-I-Y-A | 1064 | 3 | 0.019 | 0.038 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>9.69
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.019
θf [deg]:0.038
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>11.61
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.016
θf [deg]:0.032
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-255-I-Y-A | 1064 | 3 | 0.016 | 0.032 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>11.61
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.016
θf [deg]:0.032
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>11.61
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.016
θf [deg]:0.032
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-256-I-Y-A | 1064 | 3 | 0.016 | 0.032 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>11.61
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.016
θf [deg]:0.032
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10.7x10.7
Clear Aperture [mm]:9.6x9.6
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:15.43
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-257-I-Y-A | 1064 | 3 | 15.43 | 30.85 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10.7x10.7
Clear Aperture [mm]:9.6x9.6
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:15.43
θf [deg]:30.85
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.2
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:9.21
θf [deg]:18.41
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-258-I-Y-A | 1064 | 3 | 9.21 | 18.41 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:15
Clear Aperture [mm]:13.2
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:9.21
θf [deg]:18.41
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.26
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.71
θf [deg]:1.42
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-259-I-Y-A | 1064 | 3 | 0.71 | 1.42 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.26
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.71
θf [deg]:1.42
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.18
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.00
θf [deg]:2.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-261-I-Y-A | 1064 | 3 | 1.00 | 2.00 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.18
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.00
θf [deg]:2.00
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:20.77
θf [deg]:41.55
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-262-I-Y-A | 1064 | 3 | 20.77 | 41.55 | 10 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:20.77
θf [deg]:41.55
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.90
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.20
θf [deg]:0.41
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-263-I-Y-A | 1064 | 3 | 0.20 | 0.41 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.90
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.20
θf [deg]:0.41
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.45
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.053
θf [deg]:0.11
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-264-I-Y-A | 1064 | 3 | 0.053 | 0.11 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.45
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.053
θf [deg]:0.11
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.042
θf [deg]:0.084
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-265-I-Y-A | 1064 | 3 | 0.042 | 0.084 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.35
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.042
θf [deg]:0.084
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.17
θf [deg]:0.35
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-266-I-Y-A | 1064 | 3 | 0.17 | 0.35 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.05
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.17
θf [deg]:0.35
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.091
θf [deg]:0.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-267-A-Y-A | 1064 | 3 | 0.091 | 0.18 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.091
θf [deg]:0.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.81
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.23
θf [deg]:0.45
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-268-I-Y-A | 1064 | 3 | 0.23 | 0.45 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.81
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.23
θf [deg]:0.45
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.60
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.11
θf [deg]:0.23
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-269-I-Y-A | 1064 | 3 | 0.11 | 0.23 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.60
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.11
θf [deg]:0.23
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>7.98
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.023
θf [deg]:0.046
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-270-I-Y-A | 1064 | 3 | 0.023 | 0.046 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>7.98
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.023
θf [deg]:0.046
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.00
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:45.18
θf [deg]:90.36
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-271-I-Y-A | 1064 | 3 | 45.18 | 90.36 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.00
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:45.18
θf [deg]:90.36
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:25.19
θf [deg]:50.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-272-I-Y-A | 1064 | 3 | 25.19 | 50.38 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:25.19
θf [deg]:50.38
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:17.70
θf [deg]:35.40
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-273-I-Y-A | 1064 | 3 | 17.70 | 35.40 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:10x10
Clear Aperture [mm]:9x9
Thickness [mm]:1.524 or 2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:17.70
θf [deg]:35.40
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.68
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.11
θf [deg]:0.22
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-274-I-Y-A | 1064 | 3 | 0.11 | 0.22 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.68
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.11
θf [deg]:0.22
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.18
θf [deg]:0.36
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-276-I-Y-A | 1064 | 3 | 0.18 | 0.36 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>1.01
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.18
θf [deg]:0.36
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.068
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-277-I-Y-A | 1064 | 3 | 0.068 | 0.14 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:5
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.068
θf [deg]:0.14
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.27
θf [deg]:0.54
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-278-I-Y-A | 1064 | 3 | 0.27 | 0.54 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.67
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.27
θf [deg]:0.54
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.06
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.95
θf [deg]:5.91
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-279-I-Y-A | 1064 | 3 | 2.95 | 5.91 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.06
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.95
θf [deg]:5.91
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.09
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.05
θf [deg]:4.10
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-280-I-Y-A | 1064 | 3 | 2.05 | 4.10 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.09
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.05
θf [deg]:4.10
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.46
θf [deg]:0.92
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-283-A-Y-A | 1064 | 3 | 0.46 | 0.92 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.40
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:27.94
Clear Aperture [mm]:25.1
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.46
θf [deg]:0.92
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.24
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.76
θf [deg]:1.52
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-284-I-Y-A | 1064 | 3 | 0.76 | 1.52 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.24
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.76
θf [deg]:1.52
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:10.00
θf [deg]:20.01
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-285-I-Y-A | 1064 | 3 | 10.00 | 20.01 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:20
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:10.00
θf [deg]:20.01
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34
Thickness [mm]:3.5
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:5.16
θf [deg]:10.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-288-I-Y-A | 1064 | 3 | 5.16 | 10.32 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.04
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34
Thickness [mm]:3.5
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:5.16
θf [deg]:10.32
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.86
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.047
θf [deg]:0.095
Transmission efficiency:Close to 100%
Overall Efficiency:~ 86
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:85-115% |
||||||||
TS-289-I-Y-A | 1064 | 3 | 0.047 | 0.095 | 6 weeks | High Efficiency | ||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.86
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:20
Clear Aperture [mm]:18
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.047
θf [deg]:0.095
Transmission efficiency:Close to 100%
Overall Efficiency:~ 86
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:85-115% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.76
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.24
θf [deg]:0.48
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-291-I-Y-A | 1064 | 3 | 0.24 | 0.48 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.76
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.24
θf [deg]:0.48
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.37
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.054
θf [deg]:0.11
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-292-I-Y-A | 1064 | 3 | 0.054 | 0.11 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>3.37
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.054
θf [deg]:0.11
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:10.21
θf [deg]:20.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-293-I-Y-A | 1064 | 3 | 10.21 | 20.43 | In Stock | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:19
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:10.21
θf [deg]:20.43
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.35
θf [deg]:2.70
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-295-I-Y-A | 1064 | 3 | 1.35 | 2.70 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.14
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:21
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:1.35
θf [deg]:2.70
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:44
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.44
θf [deg]:4.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-296-U-Y-A | 1064 | 3 | 2.44 | 4.88 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:44
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.44
θf [deg]:4.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.79
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.038
θf [deg]:0.076
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-297-I-Y-A | 1064 | 3 | 0.038 | 0.076 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>4.79
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:25.4
Clear Aperture [mm]:22.9
Thickness [mm]:3
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.038
θf [deg]:0.076
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45.7
Thickness [mm]:2.29
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.44
θf [deg]:4.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-298-U-Y-A | 1064 | 3 | 2.44 | 4.88 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>0.08
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:50.8
Clear Aperture [mm]:45.7
Thickness [mm]:2.29
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:2.44
θf [deg]:4.88
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:Uncoated
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.091
θf [deg]:0.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
TS-299-I-Y-A | 1064 | 3 | 0.091 | 0.18 | 7 weeks | |||
Input Parameters
Wavelength [nm]:1064
Beam Mode (SM/MM):SM or MM
Minimum Beam Diameter [mm]:>2.02
Element Parameters
Element Type:Window
Material:Fused Silica
Element Size [mm]:38.1
Clear Aperture [mm]:34.3
Thickness [mm]:3.5
Coating:AR/AR coating
Output Parameters
Number of Spots:3
Separation Angle [deg]:0.091
θf [deg]:0.18
Transmission efficiency:Close to 100%
Overall Efficiency:~ 84
Uniformity (Contrast) [%]:<1%
Zero - Order relative to
the average [%]:70-130% |
||||||||
Need shorter lead time? Lead time of uncoated DOE is 4 weeks shorter!Click here for RFQ and questions
|
Loading, Please Wait...
Holo/Or offers Diffractive Optical Elements in a wide variety of wavelength between 180nm and 11um
For DOE solutions outside this range, please contact us for custom solutions.
Materials | Fused Silica, Sapphire, ZnSe, Germanium, Plastic |
---|---|
Wavelength range | 193nm to 10.6um |
DOE design | 2-level (binary) to 16-level |
Full angle | 0.001° to 80° (larger angles require additional optics) |
Diffraction efficiency | 64% - 98% |
Element size | Few mm to 150mm |
Coating (optional) | AR/AR Coating |
Custom Design | Almost any symmetry or arbitrary shape |
Features:
- Single Mode or Multimode input beam laser
- High power threshold
- Glass or plastic materials
- Accurate angle separation
- Insensitive to X-Y-Z displacements
- Custom separation angle and shape
- Any input beam shape
- Wavelengths from UV to IR
- Optional Ar/Ar coating
Applications:
- Parallel material processing
- Medical/aesthetic treatment
- Laser scribing (solar cells)
- Glass dicing (LCD displays)
- Laser display & illumination
- Machine vision & 3D sensors
- Fiber optics
